Replacement Parts For Model 3659

Replacement Parts For Model 3659

Image	Parts Breakdown	Part #	Description	Qty	Price
	Download File	1303-1S	FLAT HEAD ALLEN SCREWS (2)		$0.80
	Download File	1314-4	COUNTERWEIGHT 3500-3950		$12.53
	Download File	1315-8	MOTOR HOUSING MULTI-OPTION		$54.71
	Download File	1319-4	CRANK & DRIVE HEAD ASSY 3500		$46.94
View Image Click for Larger Version	Download File	1320	SPINDLE LOCK RING		$1.18
View Image Click for Larger Version	Download File	1320-1	HUB LOCK RING		$1.18
View Image Click for Larger Version	Download File	1321-CW	BEARING PLATE WASHER ONLY		$1.96
	Download File	1323-2S	MOTOR VANE SET (5)-3500 SERIES		$9.39
	Download File	1324-4	MOTOR ROTOR MODEL 3500-3950		$21.76
	Download File	1325-4	MOTOR CYLINDER MODEL 3500-3950		$30.44
	Download File	1325-6	CYLINDER ALIGNMENT KEY		$1.09
	Download File	1328-3	BLUE CAP-MODEL 3500-3950		$22.57
	Download File	1329	TRIGGER		$13.25
	Download File	1333	AIR VALVE SPRING		$1.75
	Download File	1336-1	VALVE PLUNGER		$5.11
	Download File	1336-G	VALVE PLUNGER GUIDE		$4.58
View Image Click for Larger Version	Download File	1342-1	BEARING SPACER 3500 SERIES		$0.87
	Download File	1343S	MOTOR HOUSING SCREW SET (4)		$1.75
	Download File	1344-3	DRIVE HEAD 3500 SERIES		$40.39
	Download File	1345-5P	DUST SEAL RING-3950/3960/3970		$3.64
	Download File	1345-PV	BLUE VA SHROUD MODEL 3950		$30.51
	Download File	1345S	SHROUD SUPPORT SCREW SET (3)		$1.32
	Download File	1352P	MUFFLER MODEL 3500		$12.38
	Download File	1352-PVN	VACUUM TUBE SWIVEL COMP		$12.05
View Image Click for Larger Version	Download File	1712-1	LOWER SPINDLE BEARING		$23.65
View Image Click for Larger Version	Download File	1712-2	UPPER SPINDLE BEARING		$23.65
View Image Click for Larger Version	Download File	1810-1	MOTOR BEARING 3500/3560		$13.47
View Image Click for Larger Version	Download File	1820	WOODRUFF KEY		$0.80
	Download File	1821-F	BEARING PLATE ONLY		$16.38
	Download File	1822	ROTOR RETAINER CLIP		$0.96
	Download File	1830S	TRIGGER SCREW SET		$1.61
	Download File	1937-3	AIR CONTROL -3500/3560/3570		$6.20
	Download File	1937-S	AIR CONTROL VALVE SET SCREW		$1.09
